NarcBox XL

Specifications:

Mechanical:

External Dimension: 10″ x 13.5″ x 4″

Internal Dimensions: 8″ x 12″ x 3.6″

Interface: 3.2″ Resistive-touch (works with gloves)

External power reset

Fingerprint biometric option available

RFID Capable, Biometrics optional

Includes one RFID Card and one RFID Key Fob

​

External Power:

Dual receptacle 2.5mm x 5.5mm Barrel Jack

12V Nominal Input (automotive spec compliant)

Max current draw: 1.5A

​

Battery:

LifePo4 1600maH

3000 Charge cycle life minimum

Max battery life: 50-hours

Battery life is dependent upon how much time the NarcBox spends in the “awake” state, and how many times the door has been opened, while on battery power. The above max specification assumes the NarcBox has been asleep 95% of the time, and opened less than 10-times.

​

Wifi:

2.4 Ghz IEEE 802.11b/g

802.11b Compatibility: DSSS (CCK-11, CCK -5.5, DAPSK-2, DBPSK-1)

Encryption: AES 128

Internal patch antenna

Security:

WEP-128​

WPA-PSK (TKIP)

WPA2-PSK (AES)

​

System:

Operating Temperature Range: -40C to +85C (+176F)

Screen rotation detection for any mounting orientation

Medication Tracking (configurable via website

Over-The-Air Firmware updates
